DEPAI 2 Colors Flexographic Printing Machine For Plastic Bag

FOB Reference Price:Get Latest Price
$6,000.00 - $15,000.00 / Piece | 1 Piece/Pieces (Min. Order)
Model Number:
DP-FP2600
Gross Power:
18kw
Report Suspicious Activity
Overview
Quick Details
Type:
Flexographic Printer
Applicable Industries:
Manufacturing Plant
After Warranty Service:
Online support
Local Service Location:
None
Showroom Location:
None
Condition:
New
Plate Type:
Letterpress
Place of Origin:
Zhejiang, China
Brand Name:
DEPAI
Usage:
Label Printer, plastic bags and non woven fabric
Automatic Grade:
Automatic
Color & Page:
MULTICOLOR
Voltage:
220V 50hz
Dimensions(L*W*H):
2300*1860*2145mm
Weight:
1800kgs
Certification:
CE Certification
Warranty:
1 YEAR
After-sales Service Provided:
Online support, Video technical support, Engineers available to service machinery overseas
Key Selling Points:
Multi Color
Printing material:
Nonwoven Fabrics, PE, PVC PP and tec.
Color:
2 color
Printing Speed:
max 80m/min
Machine type:
flexo printing machine
Machine color:
as your request
Material:
cast iron with spray paint
Spare Parts:
tool box, hand wheel, handle valve, English manual and heating tube
Standard configuration:
motor,electrical,inverter, breaker and ac contactor
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
Export and sea-worthy standard wooden case + wrapping film
Port
NINGBO and SHANGHAI

2 color Flexographic Printing Machine







Feature:

1.     Easy operation, gentle starting, accurate color print.

2.     The meter counter can set print quantity according the requirements, stop the amchine automatically at the quantity or when the material is cut off.

3.     After lifting and lowering the printing plate cylinder manunally, It will automatically stir the printing in.

4.     The printing in is spread by the anilox cylinder riller with evenly ink.

5.     Reliable dry system, coordinate high-speed opration, wngine off automatic abruption.

6.     360degrees continuously adjustable longiyudinal to register device.

7.     Frequency conversion velocity modulation, adaption differnet ponting speed.

8.     On the version roller sear and receives on material to be loaded with the spot to move and the pause button, is advantage for when the justification operates the machine.



Application

Introduce sensitization resin as flexible printing plate, suitable for printing such packing materials as polyethylene, polypropylene bag, cellophane and roll paper, etc. It is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.



Materials:

Raw Material:  PE, PVC, PP, Non Woven and etc.


Frequency:


Printing Speed:10-80m/min


Specification:



Model DP-FP2600DP-FP2800DP-FP21000DP-FP21200
Max. Web Width600mm800mm1000mm  1200mm
Max. Effective     Printing Width560mm760mm960mm1160mm
Range of Repeat Printing Length191-914mm191-914mm191-914mm191-1000mm
Max. Diameter of Roller Material600mm600m600mm600mm
Printing Speed50m/min50m/min50m/min80m/min
   Plate Thickness      (Both side adhesive tape included)2.38mm2.38mm2.38mm2.38mm
Total Power8kw10kw12kw7.8kw
Machine Weight1800kgs2000kgs2200kgs2400kgs
Overall Dimension2300*1860*2145mm2300*2060*2145mm2300*2260*2145mm2300*2260*2145mm
OptionalAutomatic tension control system,  Automatic correct edge system, A separate discharging and feeding system.





Deatils:

Installation, Adjusting & Commissioning:
Installation and Adjusting: The seller will for certain dispatch the technician to your country for installation, commissioning, adjusting the machine and training the workers in your plant. However the buyer should take on all costs required during our technician’s stay in the buyer’s country, round airplane tickets, accommodation, foods.should be responsible for the cost of supplier's technician.Salary80 USD/DAY

Company Overview:

HANGZHOU DEPAI MACHINERY Co.,Ltd is professional manufacturer of plastic bags making machine, flexographic printing machine, film blowing machine, drinking straw machine and die cutting machine for more than 15 years. The company is located in HANGZHOU, capital of Zhejiang province, with excellent geographical location and convenient transportation. Furthermore, the company owns a professional after-sales service team who can provide customers with comprehensive solutions and technical support.


Guarantee terms:

The seller guarantee the machines are new (or unused) and the guarantee period will be given 12 (twelve) months which starts from the date of the machine’s arrival. During this period, the seller will provide free maintenance and free spare parts that caused by the machine’s quality, but the buyer must pay the round trip tickets and accommodation expenses for seller’s technicians.



FAQ

1. Q: How does your factory do regarding quality control?
A: Quality is priority. We always regard great importance to quality controlling from the very small thing (even a small screw we will choose the best quality) from the beginning.



2. Q: What is your after-sales service?
A: Our after-sales service is first class. We have a powerful team to help you solve problems.The Warranty is one year and if the machine is damaged by natural not by human, we can send the new parts to you for free.


3. Q: What is the terms of payment you accept?
A: 30% T/T in advance, 70% T/T balance before delivery. We also accept L/C and Western Union.
